Box-PC Slim C-K2

  • Konfigurieren Sie Ihr Box-PC System

    CPU
    Arbeitsspeicher
    Festplatten-Speicher
    Netzteil
    Montage
    Betriebssystem

Box-PC Slim C-K2 – Industrie-Power auf kleinem Raum

Der Box-PC Slim C-K2 überzeugt durch kompakte Bauform, Hutschienenmontage und robuste Leistung im Temperaturbereich von -20° bis +60 °C. Ausgestattet mit Intel® CPUs der 12. Generation (i3, i5, i7), 2x GbE-LAN, 6x USB 3.2 sowie HDMI & DisplayPort für zwei Monitore – perfekt für anspruchsvolle Industrieanwendungen im Schaltschrank.

Box-PC Slim C-K2
CPUIntel® Core™ i3-1215U, 6x 3.30GHz/4.40GHz
Intel® Core™ i5-1235U, 10x 3.30GHz/4.40GHz
Intel® Core™ i7-1255U, 10x 3.50GHz/4.70GHz
Mainboard ChipsatzIntel® SoC
GrafikIntel® Iris® Xe Graphics
KühlungPassiv
Arbeitsspeicher4GB DDR4 RAM, 1x SO-DIMM, max. 32GB
Festplatten-Schnittstellen1x M.2 2280 Key M (NVMe)
RAID-Level–
Netzwerk2x GbE LAN, Intel® 226-V, Intel® I219-AT
USB6x USB 3.2 Gen1 (w. Intel® N97 = 4x USB 3.2 Gen1, 2x USB 2.0)
Seriell/Parallel–
Video1x DisplayPort 1.2, 1x HDMI 1.4b
Audio–
Erweiterungs-Schnittstellen1x M.2 3042/3052 Key B (f. 4G/5G), 1x M.2 2230 Key E (f. WiFi & Bluetooth)
Weitere MerkmalePower Button, 2x SMA (f. Antennen), TPM2.0, Watchdog Timer (Software)
Betriebsspannung12V/24V DC, auto detect
Leistungsaufnahmemax. 50W (i7-1255U)
Betriebstemperatur-20° bis 60°C
Lagertemperatur-40° bis 80°C
Lagerluftfeuchtigkeit10% bis 95% @ 10°C, nicht kondensierend
Resistenz VibrationOperating 50Hz~500Hz / 1,5G, 0.15mm peak to Peak (w/ SSD, according to IEC60068-2-64)
Resistenz SchockOperating 1,5Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-27)
ZertifikatCE / FCC Class A
Front/GehäuseStahl/Aluminiumlegierung, anthrazit
SchutzklasseIP20
Montage/VerwendungWand, Montageplatte, Option: Hutschiene
Maße mm (B x H x T)150 x 114 x 47; Montageplatte: 194 x 114 x 47
Gewicht kgca. 1.0
ZubehörTreiber DVD, Wandmontage-Set, 2-Pin Power Terminal-Stecker
OS supportWindows® 11 64Bit, Windows® 10 64Bit, Linux, andere auf Anfrage



Bestellinformationen & Datenblätter

BestellnummerProduktnameBasiskonfiguration
CI-MO-S02-250-3Slim C-K2-3Intel® Core™ i3-1215U, 6x 3.30GHz/4.40GHz; 4GB RAM
CI-MO-S02-250-5Slim C-K2-5Intel® Core™ i5-1235U, 10x 3.30GHz/4.40GHz; 4GB RAM
CI-MO-S02-250-7Slim C-K2-7Intel® Core™ i7-1255U, 10x 3.50GHz/4.70GHz; 4GB RAM
