Name: 19" Rack-PC 4HE T2-65
SKU: 6739
Availability: InStock

19″ Rack-PC 4HE T2-65
Housing height	4HE
Dimensions mm (H x W x D)	Installation: 178 x 433 x 650 Total: 178 x 482 x 695
Installation depth mm (without connectors, etc.)	650
Motherboard form factor supported	Mini ITX, μATX, ATX, eATX, SSI EEB
Mainboard dimensions mm (L x W)	max. 305 x 330
Cooling	Fan cooling system, option: water cooling
Fan, front	2x 120mm
Fan, inside	3x 120mm
Fan, rear	2x 80mm
Graphics card	Supported, up to 330mm
5.25″ front bay/removable frame	option
3.5″ front bay/removable frame	option
2.5″ front bay/removable frame	option
3,5″ frame, center	max. 10x
2,5″ frame, center	max. 10x
Front connections	1x USB 3.0/ 1x USB 2.0
Power supply	Option
Controls	Power switch Reset button
LED	Power Hard disk activity 2x Network activity
Case material	1.0-1.2mm steel
Other features	Lockable front with dust filter. Including 7 pre-installed fans. USB 3.0/USB 2.0 accessible from the front.
Operating temperature	min. 0° up to 40°C, max. depending on the used hardware (mainboard, memory, etc.)
Storage temperature	min. -10° up to 65°C, max. depending on the used hardware (mainboard, memory, etc.)
Storage humidity	10% to 95% at 65°C non-condensing
Weight kg	ca. 15.0, without HDDs/SSDs and extensions
Accessories	depending on the desired hardware (mainboard, etc.)
OS support	Windows® 11 64Bit, Windows® 10 64Bit, others on request

Ordering information data sheets
