Tablet-PC Explorer T-H1

  • Configure your Tablet PC system

    Displaydiagonale, Auflösung
    CPU
    Arbeitsspeicher
    Festplatten-Speicher
    Netzwerk
    Mobilfunk
    Barcode Scanner
    Near Field Communication (NFC)
    Dockingstation
    KFZ Halterung
    Handhalterung
    Schultergurt
    Netzteil
    Betriebssystem
Explorer T-H1
Display10.1″, 1920×1200, 16:10 12.2″, 1920×1200, 16:10
Brightness cd/m2600
Angle of view H/V170°/170°
LED backlight life hrs30.000
Touch technologyCapacitive
Front/housingPlastic, black
Protection classIP65, front; 7H safety glass
CPUIntel® Core™ i5-1235U, 10x 3.30GHz/4.34GHz Intel® Core™ i7-1255U, 10x 3.50GHz/4.70GHz
GraphicsIntel® Iris® Xe Graphics eligible
CoolingFan
RAM8GB/16GB DDR4L RAM, SO-DIMM
Storage-interface1x M.2 2280 SSD, 1x MicroSD-Slot
NetworkWiFi 6 802.11a,b,d,e,g,h,i,k,n,r,u,v,w,ac,ax (2.4G/5.8G), Bluetooth 5.1, SIM-Card-Slot f. LTE, Option: 5G, Option: 1x LAN 10/100Mbit/s
Mobile communicationsSIM-Card-Slot Option: Modul LTE FDD B1/B3/B7/B8/B20/B28A, WCDMA: B1/B8 GSM: B3/B8 Region: Europe, Middle East, Africa, Taiwan, Japan
USB1x USB 3.0 (Typ A), 1x USB 3.0 (Typ C), Option: 1x USB 2.0
Seriell/ParallelOption: 1x RS232
NavigationGLONASS, GPS, Option: Beidou
Barcode ScannerOption: 2D Honeywell N3680 Hardcode, Auflösung: 5mil/scan, Geschwindigkeit: 50 times /s Code system: PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse Maxicode,QR Code, MicroQR, QR Inverse, Aztec, Aztec Inverses, Han Xin, Han Xin Inverse
Fingerprint ScannerYes
NFCOption
CameraFront: 2.0MP Rear: 8.0MP
G-SensorYes
Video1x Mini-HDMI 2.1a
AudioSpeaker, 1x Line-out
Extension interfaces–
Additional featuresPower button, scanner button, volume buttons, Windows® button, TPM2.0, SSD replaceable
Operating voltage19V DC
Power consumptionmax. 25W (without options)
Operating timeIntegrated battery: 7.4V/700mAh, approx. 20 minutes Battery change: 10.1″: 7.4V/5000mAh, hot-swappable, 360 minutes, at 50% volume, 200cd/m2, 1080HD video Battery change: 12.2″: 7.4V/6300mAh, hot-swappable, 360 minutes, at 50% volume, 200cd/m2, 1080HD video
Operating temperature-20°C to 60°C
Storage temperature-30° to 70°C
Storage humidity10% to 95% at 40°C non-condensing
Resistenz VibrationMil-STD-810G, Method 514.7, 3Axis, 10Minutes/Axis, 30Minutes total, Status Power on Video playing
Resistenz SchockMil-STD-810G, Method 516.7 Section 4.6.5, 26 Tests, Drop-test 122cm
CertificateTablet-PC: CE, CE-NB, CCC, MIL-STD-810G Batterie: UN3803, MSDS, IEC62133, Aviation, Ocean shipping reports
Assembly/UseMobile, Office, Logistics, Automotive
Dimensions mm (W x H x D)290 x 196 x 22
Weight kg10.1”: 1.4, incl. 5000mAh battery / 12.2”: 1.6, incl. 6300mAh battery
AccessoriesPower supply 230V AC, 19V DC, 65W, battery 7.4V/5000mAh /7.4V/6300mAh, USB OTG cable
OS supportWindows® 11 64Bit, Windows® 10 64Bitandere auf Anfrage

Ordering information data sheets



Order numberProduct nameBasic configuration
TE-MO-TH1-101-5Explorer T-H1-5-110.1″, 1920×1200, 16:10; Intel® Core™ i5-1235U, 10x 3.30GHz/4.30GHz; 8GB RAM
TE-MO-TH1-101-7Explorer T-H1-7-110.1″, 1920×1200, 16:10; Intel® Core™ i7-1255U, 10x 3.50GHz/4.70GHz; 8GB RAM
TE-MO-TH1-122-5Explorer T-H1-5-212.2″, 1920×1200, 16:10; Intel® Core™ i5-1235U, 10x 3.30GHz/4.30GHz; 8GB RAM
TE-MO-TH1-122-5Explorer T-H1-7-212.2″, 1920×1200, 16:10; Intel® Core™ i7-1255U, 10x 3.50GHz/4.70GHz; 8GB RAM
