19″ Rack-PC 2HE T1-65

  • Configure your 19" Server PC system

    Monitor

Hier weitere Informationen anfordern
19″ Rack-PC 2HE T1-65
Case height 2HE
Dimensions mm (H x B x T) Installation dimension: 89 x 433 x 650
Overall: 89 x 482 x 680
Installation depth mm (without plug connections, etc.) 650
Mainboard form factor supported Mini ITX, mATX, μATX, ATX, eATX, SSI EEB
Mainboard dimensions mm (L x W) max. 305 x 350
Cooling Fan cooling system, option: water cooling
Fan, front
Fan, center 4x 80mm
Fan, rear
Graphic card Supported up to 350mm
5.25″ front insert / removable frame 2
3,5″ front insert / removable frame
2,5″ front insert / removable frame
3,5″ frame, center max. 7x
2,5″ frame, center max. 4x
Interfaces, front 2x USB 3.0
Power supply Option
Controls On/off button
Reset button
LED Power
Hard drive activity
3x network activity
Alarm
Housing material 1,0-1,2mm steel
Other features Front with snap-in closure.
Drive housing removable and optionally positionable, 5.25″ drives can be mounted without screws.
Including 4 pre-installed fans.
USB 3.0 accessible from the front.
Operating temperature min. 0° up to 40°C, max. depending on the used hardware (mainboard, memory, etc.)
Storage temperature min. -10° up to 65°C, max. depending on the used hardware (mainboard, memory, etc.)
Storage humidity 10% to 95% bei 65°C not condensing
Weight kg approx. 9.5, without HDDs / SSDs and extensions
Accessories depending on the used hardware (mainboard, memory, etc.)
OS support Windows® 10 64Bit, others on request

Ordering information & data sheets

Download
Housing Technical drawings
Housing Data sheet
