Name: 19" Rack-PC 3HE T4-40
SKU: 5184
Availability: InStock

19″ Rack-PC 3HE T4-40
Case height	3HE
Dimensions mm (H x B x T)	Installation dimension: 133 x 433 x 400 Overall: 133 x 482 x 438
Installation depth mm (without plug connections, etc.)	400
Mainboard form factor supported	Mini ITX, mATX, FlexATX, μATX², ATX²
Mainboard dimensions mm (L x W)	max. 305 x 191
Cooling	Fan cooling system, option: water cooling
Fan, front	1x 120mm
Fan, center	–
Fan, rear	2x 60mm
Graphic card	Supported up to 191mm
5.25″ front insert / removable frame	6x
3,5″ front insert / removable frame	Option
2,5″ front insert / removable frame	Option
3,5″ frame, center	max. 12x
2,5″ frame, center	max. 14x
Interfaces, front	2x USB 3.0
Power supply	Option
Controls	On/off button Reset button
LED	Power Hard drive activity 3x network activity Alarm
Housing material	1,0-1,2mm steel
Other features	Including 3 pre-installed fans. Additional 6x 40mm fans can be optionally integrated. Drive cages removable and optionally positionable. USB 3.0 accessible from the front. Front with snap-in closure.
Operating temperature	min. 0° up to 40°C, max. depending on the used hardware (mainboard, memory, etc.)
Storage temperature	min. -10° up to 65°C, max. depending on the used hardware (mainboard, memory, etc.)
Storage humidity	10% to 95% bei 65°C not condensing
Weight kg	approx. 9.3, without HDDs / SSDs and extensions
Accessories	depending on the used hardware (mainboard, memory, etc.)
OS support	Windows® 10 64Bit, others on request

19″ Rack-PC 3HE T4-40
