Panel-PC Challenger P-T1

Panel-PC Challenger P-T1

Capacitive touch panel PCs, with 11th generation Intel® processors

The 11th generation Intel® processors ensure the high performance of the Challenger P-T1 panel PCs. Even computationally intensive tasks are solved, which until recently required 65W TDP CPUs. This is achieved not least by the powerful graphics unit (GPU) Iris® Xe (Gen12) in the processor. Intel® Deep Link technology ensures that free computing resources are intelligently distributed between the GPU and CPU, which helps increase performance.
The two LAN, four USB and up to four serial interfaces ensure high connectivity. Two large-screen displays can also be connected via the two HDMI interfaces. The front-protected IP65 Challenger P-T1 models are designed for use in server cabinets. The VESA interface also makes it possible to mount the touch panel PCs on the wall. The large passive heat sink on the back ensures that everything stays cool even in heated situations.

Whether skylight or sunlight, the Challenger P-T1 touch panel PCs always offer you the best view of your visualization. The 15″, 15.6″ and 21.5″ models are already equipped with 7H safety glass as standard. If annoying reflections or direct light on the display are to be expected during use, the anti-reflection and high brightness options offer extremely convincing solutions to maintain a clear view with the panel PCs even under these conditions.

  • Konfigurieren Sie Ihr Panel-PC System

Hier weitere Informationen anfordern

Panel-PC Challenger P-T1

Capacitive touch panel PCs, with 11th generation Intel® processors

The 11th generation Intel® processors ensure the high performance of the Challenger P-T1 panel PCs. Even computationally intensive tasks are solved, which until recently required 65W TDP CPUs. This is achieved not least by the powerful graphics unit (GPU) Iris® Xe (Gen12) in the processor. Intel® Deep Link technology ensures that free computing resources are intelligently distributed between the GPU and CPU, which helps increase performance.
The two LAN, four USB and up to four serial interfaces ensure high connectivity. Two large-screen displays can also be connected via the two HDMI interfaces. The front-protected IP65 Challenger P-T1 models are designed for use in server cabinets. The VESA interface also makes it possible to mount the touch panel PCs on the wall. The large passive heat sink on the back ensures that everything stays cool even in heated situations.

Whether skylight or sunlight, the Challenger P-T1 touch panel PCs always offer you the best view of your visualization. The 15″, 15.6″ and 21.5″ models are already equipped with 7H safety glass as standard. If annoying reflections or direct light on the display are to be expected during use, the anti-reflection and high brightness options offer extremely convincing solutions to maintain a clear view with the panel PCs even under these conditions.

Touch Panel-PC Challenger P-T1

Display 15″, 1024×768, 4:3
15.6″, 1920×1080, 16:9
21.5″, 1920×1080, 16:9
Luminance (cd/m2) 300
View Angle H/V 15″: 176°/176°
15.6″: 176°/176°
21.5″: 160°/170°
Backlight lifetime hrs. 15″: 60.000
15.6″: 50.000
21.5″: 40.000
Touch technology Capacitive
Front/Housing Steel, silver, black
Protection class IP65, front
CPU Intel® Celeron 6305E, 2x 1.80GHz
Intel® Core™ i3-1115G4E, 2x 2.20GHz/3.90GHz
Intel® Core™ i5-1145G7E, 4x 1.50GHz/4.10GHz
Intel® Core™ i7-1185G7E, 4x 1.80GHz/4.40GHz
Mainboard chipset Intel® SoC
Cooling Fanless
System memory 4GB DDR4 RAM, 1x SO-DIMM, max. 32GB
Storage-interface 1x SATA 2.5″
RAID level
Network 2x GbE LAN, 1x Intel® I219-LM, 1x Intel® I225-LM (2.5GbE)
USB 4x USB 3.1 Gen2
Serial/Parallel COM 15″: 1x RS232/422/485, 1x RS232
15.6″: 1x RS232/422/485, 3x RS232
21.5″: 1x RS232/422/485, 3x RS232
Video 2x HDMI
Audio Speaker 2x 3W
Expansion slot 1x M.2 2230 Key E, 1x M.2 2280/2260/2242/3042/3052 Key B (USB2.0/SATAIII)
Other features 7H scratch resistance glass, Power Button, Reset Button, 2-Pin Remote Power On/Off
Power input 8V to 24V DC
Power consumption Intel® Celeron 6305E: max. 38W, Intel® Core™ i: max. 60W
Operating temperature 15″: -10°C to 55°C
15.6″: -10°C to 55°C
21.5″: 0°C to 50°C
Storage temperature -20° to 60°C
Storage humidity 10% to 95% at 40°C not condensing
Vibration resistance Operating random vibration Test 5-500Hz, 2 Grms, 3Axis (w/ SSD, according to IEC60068-2-64)
Schock resistance Operating 10G peak acceleration (11 ms duration) / follow IEC 60068-2-27
Certification CE / FCC Class B
Mounting Control cabinet installation, VESA
Dimension mm (W x H x D) 15″: 360.4 x 283.4 x 81.7; Cut-out: 339 x 261
15.6″: 386.2 x 235.6 x 83.0; Cut-out: 375 x 225
21.5″: 508.0 x 308.0 x 83.0; Cut-out: 497 x 297
Weight kg 15″: 4.8
15.6″: 5.0
21.5″: 8.0
Accessories Driver DVD, Quick Installation Guide, Mounting kit, 3-pin terminal connector
OS support Windows® 10 64Bit, others on request

Ordering information & data sheets

Order number Product name Basic configuration
PM-SE-T01-150-1 Challenger P-T1-15-1 15″, 1024×768, 4:3; Celeron® 6305E; 4GB RAM
PM-SE-T01-150-3 Challenger P-T1-15-3 15″, 1024×768, 4:3; Intel® Core™ i3-1115G4E; 4GB RAM
PM-SE-T01-150-5 Challenger P-T1-15-5 15″, 1024×768, 4:3; Intel® Core™ i5-1145G7E; 4GB RAM
PM-SE-T01-150-7 Challenger P-T1-15-7 15″, 1024×768, 4:3; Intel® Core™ i7-1185G7E; 4GB RAM
PM-SE-T01-156-1 Challenger P-T1-16-1 15.6″, 1920×1080, 16:9; Intel® Celeron® 6305E; 4GB RAM
PM-SE-T01-156-3 Challenger P-T1-16-3 15.6″, 1920×1080, 16:9; Intel® Core™ i3-1115G4E; 4GB RAM
PM-SE-T01-156-5 Challenger P-T1-16-5 15.6″, 1920×1080, 16:9; Intel® Core™ i5-1145G7E; 4GB RAM
PM-SE-T01-156-7 Challenger P-T1-16-7 15.6″, 1920×1080, 16:9; Intel® Core™ i7-1185G7E; 4GB RAM
PM-SE-T01-215-1 Challenger P-T1-21-1 21.5″, 1920×1080, 16:9; Intel® Celeron® 6305E; 4GB RAM
PM-SE-T01-215-3 Challenger P-T1-21-3 21.5″, 1920×1080, 16:9; Intel® Core™ i3-1115G4E; 4GB RAM
PM-SE-T01-215-5 Challenger P-T1-21-5 21.5″, 1920×1080, 16:9; Intel® Core™ i5-1145G7E; 4GB RAM
PM-SE-T01-215-7 Challenger P-T1-21-7 21.5″, 1920×1080, 16:9; Intel® Core™ i7-1185G7E; 4GB RAM
