Name: Box-PC Snap C-N3
SKU: 6890
Availability: InStock

Box-PC Snap C-N3
CPU	Intel® Celeron® J6412, 4x 2.00GHz/2.6GHz
Mainboard chipset	Intel® SoC
Graphics	Intel® UHD-Graphics
Cooling	Fanless
System memory	4GB DDR4 RAM, 1x SO-DIMM, max. 32GB
Storage-interface	1x M.2 2280 Key M (SATA)
RAID level	–
Network	3x 2.5GbE LAN, 3x Intel® I225-V
USB	4x USB 3.0, 2x USB 2.0
Serial/Parallel COM	2x RS232/422/485
Video	1x HDMI, 1x DP
Audio	1x Line-out/Mic-in
Expansion slot	1x Mini PCIe full size/half size
Other features	Power Button, 4x SMA (for antennas), TPM2.0
Power input	9V bis 36V DC
Power consumption	max. 30W
Operating temperature	-10° to 60°C
Storage temperature	-20° to 80°C
Storage humidity	10% to 95% non-condensing
Vibration resistance	Operating 5Hz~500Hz / 1,5Grms / 3Axis (w/ SSD, according to IEC60068-2-64)
Schock resistance	Operating 1,5Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-27)
Certification	CE / FCC Class A
Front/Housing	20 / 5.000 Steel, silver/black
Protection class	IP20
Mounting/Use case	DIN rail, wall, mounting plate
Dimension mm (W x H x D)	Top hat rail: 57 x 185 x 145; mounting plate: 57 x 230 x 145
Weight kg	ca. 1.5
Accessories	Driver DVD, Wall Mounting Kit, 3-Pin Power Terminal Connector
OS support	Windows® 10 64Bit, Windows® 11 64Bit, Linux, others on request

Order number	Product name	Basic configuration

CI-MO-N03-620-1	Snap C-N3	Intel® Celeron® J6412, 4x 2.00GHz/2.60GHz; 4GB RAM
