Box-PC Sparkle C-A1
zzgl. Versandkosten
Box-PC Sparkle C-A1 |
|
CPU | Intel® N97, 4x to 3.60GHz Intel® i3-N305, 8x to 3.80GHz |
Mainboard | ChipsatzIntel® SoC |
Grafik | Intel® HD Graphics |
Cooling | Passive |
System memory | 8GB DDR5 RAM, 1x SO-DIMM, max. 16GB |
Hard drive interfaces | 1x SATA 2.5″, 1x M.2 2280 (SATA/NVMe), 1x M.2 2242 (SATA) |
RAID-Level | – |
Network | 2x 2.5GbE LAN, 2x Intel® I226V |
USB | 3x USB 3.2 Gen2, 1x USB 3.1 (Typ-C), 2x USB 2.0 |
Seriell/Parallel | 1x RS232/422/485, 3x RS232 (i3-N305) / 1x RS232 (N97) |
Video | 1x HDMI 1.4, 1x DisplayPort 1.4 |
Audio | 1x Line-out/Mic-in |
Expansion slot | 1x M.2 2230 Key E (PCIe x1, USB 2.0), 1x M.2 2242/3042/3052 Key B (PCIe x1, USB 2.0, SATA) |
Other features | Power button, 2x SMA (for antennas), 2-pin reset/remote power on/off, TPM2.0, 8-bit GPIO 10-pin terminal block (i3-N305) |
Operating voltage | 8V to 26V DC |
Power consumption | max. 35W (i3-N305, without options) |
Operating temperature | -20° to 60°C |
Storage temperature | -30° to 80°C |
Storage humidity | 10% to 95% at 80°C, non-condensing |
Resistenz Vibration | 5~500Hz, 2Grms, 3Axis, according IEC60068-2-64 |
Resistenz Schock | 50 Grms, Half-sine 11 ms Duration, according IEC60068-2-27 |
Zertifikat | CE / FCC Class A |
Front/housing | Aluminum alloys / steel, black |
protection class | IP20 |
Montage | Wand, Montageplatte, Option: Hutschiene, VESA |
Dimensions mm (B x H x T) | 171 x 57 x 133 |
Weight kg | ca. 2.1 |
Accessories | Driver DVD, wall mounting set, 2x 2-pin terminal connector |
OS support | Windows® 11 64Bit, Windows® 10 64Bit, Linux, |
Order number | Product name | Basic configuration |
CI-MO-A01-660-1 | Sparkle C-A1-1 | Intel® N97, 4x bis 3.60GHz; 8GB RAM |
CI-MO-A01-660-3 | Sparkle C-A1-3 | Intel® i3-N305, 8x bis 3.80GHz; 8GB RAM |
