Name: Box-PC Connector C-J6
SKU: 6329
Availability: InStock

Box-PC Connector C-J6
CPU	Intel® Celeron® J6412, 4x 2.00GHz/2.6GHz
Mainboard chipset	Intel® SoC
Graphics	Intel® UHD-Graphics
Cooling	Fanless
System memory	4GB DDR4 RAM, SO-DIMM, max. 32GB
Storage-interface	1x SATA 2.5″, 1x M.2 (SATA)
RAID level	–
Network	3x 2.5GbE LAN, 3x Intel® I225-V
USB	4x USB 3.0, 6x USB 2.0
Serial/Parallel COM	4x RS232/422/485, 2x RS232
Video	1x HDMI, 1x DP
Audio	1x Line-out/Mic-in
Expansion slot	1x Mini PCIe full size/half size
Other features	Power button, 2-pin reset/remote power on/off, 4x SMA (for antennas), TPM2.0
Power input	9V bis 36V DC
Power consumption	max. 20W (without options)
Operating temperature	-10° to 60°C
Storage temperature	-20° to 80°C
Storage humidity	10% to 95% non-condensing
Vibration resistance	Operating 5Hz~500Hz /0.026 G2/Hz / 2,16Grms / 3Axis (w/ SSD, according to IEC60068-2-64)
Schock resistance	Operating 2,16Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-27)
Certification	CE / FCC Class A
Front/Housing	Steel, silver
Protection class	IP20
Mounting/Use case	Wall, mounting plate
Dimension mm (W x H x D)	220 x 62 x 145
Weight kg	ca. 2.3
Accessories	Driver DVD, Wall Mounting Kit, 2-Pin Power Terminal Connector, 2-Pin Reset/Remote Power On/Off Terminal Connector
OS support	Windows® 10 64Bit, Windows® 11 64Bit, Linux, others on request

Order number	Product name	Basic configuration

CI-MO-J06-640-1	Connector C-J6	Intel® Celeron® J6412, 4x 2.00GHz/2.60GHz; 4GB RAM
