| Box-PC Adler C-N2 | |
| CPU | Intel® N97, 4x bis zu 3.6GHz |
| Mainboard | ChipsatzIntel® SoC |
| Grafik | Intel® UHD-Graphics |
| Cooling | Passive |
| System memory | 4GB DDR4 RAM, 1x SO-DIMM, max. 16GB |
| Storage-interface | 1x M.2 2280 Key M (SATA) |
| RAID-Level | – |
| Network | 2x GbE LAN, 2x Intel® I210-AT |
| USB | 4x USB 3.0, 2x USB 2.0 |
| Seriell/Parallel | 2x RS232/485 |
| Video | 1x HDMI, 1x DP, VGA |
| Audio | – |
| Expansion interfaces | 1x Mini PCIe full size/half size |
| Other features | Power button, reset button, 2-pin reset/remote power on/off, AT/ATX switch, 4x SMA (for antennas), TPM2.0 |
| Operating voltage | 12V to 28V DC |
| Power consumption | max. 30W |
| Operating temperature | -10° to 55°C |
| Storage temperature | -20° to 80°C |
| Storage humidity | 10% to 95% @40°C, non-condensing |
| Resistenz Vibration | With SSD: IEC 60068-2-64 (3Grms @5~500Hz, random, 1 hr/axis) |
| Resistenz Schock | With SSD: IEC 60068-2-27 (30G, half sine, 11ms) |
| Zertifikat | CE / FCC Class A |
| Front/housing | Aluminum alloy, silver gray |
| protection class | IP20 |
| Mounting/Use | DIN rail, wall, mounting plate |
| Dimensions mm (W x H x D) | DIN rail: 53 x 186 x 165; mounting plate: 53 x 214 x 147 |
| Weight kg | approx. 1.4 |
| Accessories | Driver DVD, wall mounting kit or DIN rail kit, 4-pin power terminal connector |
| OS support | Windows® 11 64Bit, Windows® 10 64Bit, Linux, |
