19″ Rack-PC 1HE T4-40
zzgl. Versandkosten
19″ Rack-PC 1HE T4-40 | |
Case height | 1HE |
Dimensions mm (H x B x T) | Installation dimension: 44 x 433 x 400 Overall: 44 x 482 x 428 |
Installation depth mm (without plug connections, etc.) | 400 |
Mainboard form factor supported | Mini ITX, mATX², FlexATX, μATX², ATX² |
Mainboard dimensions mm (L x W) | max. 305 x 191 |
Cooling | Fan cooling system |
Fan, front | – |
Fan, center | 2x 40mm |
Fan, rear | – |
Graphic card | Supported up to 191mm |
5.25″ front insert / removable frame | 2x |
3,5″ front insert / removable frame | Option |
2,5″ front insert / removable frame | Option |
3,5″ frame, center | max. 2x |
2,5″ frame, center | max. 8x |
Interfaces, front | 2x USB 3.0 |
Power supply | Option |
Controls | On/off button Reset button |
LED | Power Hard drive activity 3x network activity Alarm |
Housing material | 1,0-1,2mm steel |
Other features | Standard 2x 40mm fans. Universal ATX cover. USB 3.0 accessible from the front. Riser slot screwless mounting. |
Operating temperature | min. 0° up to 40°C, max. depending on the used hardware (mainboard, memory, etc.) |
Storage temperature | min. -10° up to 65°C, max. depending on the used hardware (mainboard, memory, etc.) |
Storage humidity | 10% to 95% bei 65°C not condensing |
Weight kg | approx. 5.5, without HDDs / SSDs and extensions |
Accessories | depending on the used hardware (mainboard, memory, etc.) |
OS support | Windows® 10 64Bit, others on request |
⇒ Intel® Core™ i3/i5/i7/i9/Xeon
⇒ Installation depth 400mm
⇒ Front: 2x USB 3.0
⇒ Fan 3x integrated
⇒ Up to 20x HDD/SSD
⇒ Front slot Option
⇒ Front with Snap-in closure
exkl. 19 % MwSt.
zzgl. Versandkosten
⇒ Intel® Core™ i3/i5/i7/i9/Xeon
⇒ Installation depth 470mm
⇒ Front: 2x USB 2.0
⇒ Fan 2x integrated
⇒ Up to 10x HDD/SSD
⇒ Front slot Option
⇒ Lockable front
exkl. 19 % MwSt.
zzgl. Versandkosten
⇒ Intel® Core™ i3/i5/i7/i9/Xeon
⇒ Installation depth 550mm
⇒ Front: 2x USB 3.0
⇒ Fan 4x integrated
⇒ Up to 20x HDD/SSD
⇒ Front slot Option
⇒ Front with Snap-in closure
exkl. 19 % MwSt.
zzgl. Versandkosten
⇒ Intel® Core™ i3/i5/i7/i9/Xeon
⇒ Installation depth 480mm
⇒ Front: 2x USB 3.0
⇒ Fan 2x integrated
⇒ Up to 10x HDD/SSD
⇒ Front slot Option
⇒ Riser Slot screwless
exkl. 19 % MwSt.
zzgl. Versandkosten
