| Runner C-A2 | |
| CPU | Intel® Celeron® J1900, 4x 2.00GHz/2.42GHz |
| Mainboard chipset | Intel® SoC |
| Graphics | Intel® HD Graphics |
| Cooling | Fanless |
| System memory | 4GB DDR3L RAM, SO-DIMM, max. 8GB |
| Storage-interface | 1x SATA 2.5″, 1x mSATA, 1x mSATA, 1x CFast |
| RAID level | – |
| Network | 2x GbE LAN, Intel® I210-AT |
| USB | 1x USB 3.0, 4x USB 2.0 |
| Serial/Parallel COM | 2x RS232/422/485 |
| Video | 1x DP, 1x DVI-I |
| Audio | 1x Line-out, 1x Mic-in |
| Expansion slot | 2x Mini PCIe full size |
| Other features | Power Button, 2-Pin Reset/Remote Power On/Off, 2x SIM-Card-Slot, 6x SMA, 4x DI, 4x DO |
| Power input | 9V to 48V DC |
| Power consumption | max. 18W |
| Operating temperature | -40° to 60°C |
| Storage temperature | -40° to 80°C |
| Storage humidity | 10% to 95% non-condensing |
| Vibration resistance | Operating 5Hz~500Hz / 5Grms / 3Axis (w/ SSD, according to IEC60068-2-64) |
| Schock resistance | Operating 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-27) |
| Certification | CE / FCC Class A |
| Front/Housing | Steel, black |
| Protection class | IP20 |
| Mounting/Use case | Wallmount, DIN rail |
| Dimension mm (W x H x D) | 168 x 47 x 135 |
| Weight kg | approx. 1.1 |
| Accessories | Driver DVD, Quick installation guide, Wall mounting-Set, DIN rail-Set, 3-Pin Terminal-Stecker |
| OS support | Windows® 10 32Bit, Windows® 10 64Bit, Linux, others on request |
Ordering information & data sheets
| Order number | Product name | Basiskonfiguration |
| CA-MO-A02-100-1 | Runner C-A2-1 | Intel® Celeron® J1900, 4x 2.00GHz/2.42GHz; 4GB RAM |
